Advanced mechanical design tools
without compromise
Professional, familiar DWG‐based 2D & 3D CAD for mechanical design and drafting.
* Free 30-day trial, no credit card required.
Fastest path to production
Start with any design data, add details and then quickly generate complete and accurate production materials.
“BricsCAD Mechanical has enabled our team to set even higher standards for structural and mechanical drawings”
Melvin Hamar, engineer at Asto Shipyard
Efficient 2D detailing
BricsCAD offers the best and most familiar workflow for turning your mechanical designs into production drawings.
Import and export all types of files with BricsCAD
Available by default in BricsCAD:
- DWG/DXF/DWT
- SketchUp® (import)
- ACIS SAT
- Images (TIFF, JPEG, etc.)
Communicator for BricsCAD®
A BricsCAD add-on to seamlessly import 3D geometry and PMI data from all major CAD applications.
Import and export other file formats for:
