Site Grading

Quickly create and modify TIN surfaces, gradings, and alignments for site design.

Requires

BricsCAD for Civil - heatmap
BricsCAD for Civil-2D
Slide
civil-gradings

Gradings

Create a graded surface on an existing topographic surface. Defining a graded area can be accomplished by selecting a previously drawn open or closed polyline as entity. Grading is used in site design and land development for terracing or land leveling to make parking lots, building pads, driveways, recreation reserves, and many more.

BricsCAD for Civil - Point cloud filtering

Smart Point Cloud filtering

NEW

Create digital terrain models from large point clouds with our intelligent filtering feature. BricsCAD Pro can create TIN Surfaces from large files by intelligently filtering points at similar elevations based on user defined parameters. This allows large point clouds to be used without compromising on the accuracy of the final model.

civil-tin-surfaces

TIN surfaces

A TIN surface is a 3D representation of a particular topographic surface. This continuous surface, consisting entirely of triangular facets, can be manipulated, edited and rendered to three-dimensional visualizations. The topographical surface can be generated based on drawing entities, data imported from a point file (CSV or TXT), points placed at different elevations, created from Civil 3D surface or imported from LandXML.

alignments

Alignments

You can update Corridors in real-time by dragging their 3D Alignment. Horizontal and vertical Alignments now support Endpoint, Midpoint and Nearest eSnaps. Horizontal Alignments also support Perpendicular eSnaps, too. Horizontal and 3D Alignments can calculate their intersections with other curves. The Properties Panel now displays Properties for Spiral-Curve-Spiral elements. Vertical Alignments support Endpoint, Midpoint, Perpendicular, Intersection and Nearest eSnaps. A new option lets you select a 3D Alignment when creating a Vertical Alignment view. In BricsCAD V21, Vertical Alignments now support parabolic curves.

civil-corridors

Create corridors for road design

A corridor is a BricsCAD Civil drawing object used for modeling three-dimensional linear objects such as roads, railway, retaining walls, and bridges. It principally consists of a 3D alignment of the linear object and its cross-section (template and template elements).

Innovative Road Design Tools

Combine traditional cross section templates with string-based design to automate common design tasks.

Requires

civil-intersections

Intersections

Create intersections automatically based on user defined parameters. Curb returns can be edited individually to meet any horizontal or vertical design criteria.

civil-round-abouts

Round-abouts

Quickly establish elevations around your selected island and edge of carriageway alignments to suit your intersection levels, as well as assigning cross sections to describe your internal island.

civil-cul-de-sacs

Cul-de-sacs

Design and edit cul-de-sacs easily by entering the desired criteria.

civil-knuckles

Knuckels

Create Knuckles quickly by entering values into a form. You have full control over your design by editing alignments and profiles of any string.

civil-autocreate-roads-and-intersections

Autocreate roads and intersections

Auto Create Roads and Intersections from polylines and default design criteria.

civil-model-viewer

Model viewer

Civil Site Design can open multiple windows showing vertical and cross section designs and these can be place across multiple monitors.

civil-modeless-dialog-boxes

Modeless dialog boxes

Modeless dialog boxes let you see the profile, section, and model update in real time as you edit.

Robust Pipe Design Tools

Quickly layout and edit pipe networks while avoiding crossing pipes, synchronized with the road model.

Requires

civil-robust-pipe-design-tools
civil-layout-tools

Layout Tools

Quickly layout and create your pipe network by either clicking on screen or create directly from polylines or alignments.

civil-editing-tools

Editing tools

In the Vertical Design Window you get access to all editing tools for the selected design elements such as editing the vertical design profiles and cross sections, establish cut/fill bulking factors, generating summary volume reports and creating surface models of your designs.

civil-crossing-pipes

Crossing pipes

Civil Site Design Pipes includes all the tools you need to quickly create your pipe networks and avoid crossing services and other pipe networks.

civil-compatible-with-industry-standard-data-formats


Compatible with industry standard data formats

Civil Site Design running on BricsCAD® is compatible with industry standard data formats. Not only will you be creating 100% compatible DWG files, but you can also open Civil 3D drawings and view the Civil 3D objects without installing an object enabler.

World Class CAD Engine
100% DWG compatible
CAD drafting tools you know
Surfaces
Alignments

US$711 one-time fee

3RD PARTY APPLICATION

Advanced road design
Robust site grading
Surface modeling
Pipe design
Sheet creation
